Overhead mechanical stirrers Hei-TORQUE
Hei-TORQUE Core
These agitators are the lightest. The compact design allows for integration in closed systems, such as fume hoods, reactors, or production systems. Suitable for low- to medium-viscosity media up to 25 l. They have a timer and 'Max' button for short-term operation at maximum speed.
Rod rack for 10.5 mm diameter maximum rods.
Hei-TORQUE Expert
These agitators are ideal for standard stirring tasks. They are designed to mix and disperse media that require no reproducible results in high viscosity applications. Feature monochrome display.
Rod rack for 10.5 mm diameter maximum rods.
Hei-TORQUE Ultimate
These agitators are ideal for demanding tasks and have to be reproducible and documentable. The large number of additional features and modes of operation allow perfect adjustment to your individual application. They have color display, timer and USB/RS-232 interface.
The new powerful agitators rods Series Hei-TORQUE have a sealed housing that meets the high IP 42 (Hei-Torque Core) and IP 54 (Hei- Torque Expert/Ultimate), for maintenance-free operation 24 hours, even in an aggressive environment, the only Quick-Chuck system the change of the rods without tools. Safe start and stop operation through the sliding touch panel to avoid unintentional agitation in Hei-TORQUE Ultimate models.
Hei-TORQUE Core
These agitators are the lightest. The compact design allows for integration in closed systems, such as fume hoods, reactors, or production systems. Suitable for low- to medium-viscosity media up to 25 l. They have a timer and 'Max' button for short-term operation at maximum speed.
Rod rack for 10.5 mm diameter maximum rods.
Hei-TORQUE Expert
These agitators are ideal for standard stirring tasks. They are designed to mix and disperse media that require no reproducible results in high viscosity applications. Feature monochrome display.
Rod rack for 10.5 mm diameter maximum rods.
Hei-TORQUE Ultimate
These agitators are ideal for demanding tasks and have to be reproducible and documentable. The large number of additional features and modes of operation allow perfect adjustment to your individual application. They have color display, timer and USB/RS-232 interface.
Hei-TORQUE Core Power supply (W)
105 Speed (rpm)
20-2000 Maximum torque (Ncm)
40 Maximum viscosity (mPas)
10000 Speed indicator
Electronic Maximum stirring volume (l)
25 Weight (Kg)
2.3 Dimensions WxHxD (mm)
70x281.5x195 Pack (u.)
1
Hei-TORQUE Expert 100 Power supply (W)
90 Speed (rpm)
10-2000 Maximum torque (Ncm)
100 Maximum viscosity (mPas)
60000 Speed indicator
Electronic Maximum stirring volume (l)
50 Weight (Kg)
4.4 Dimensions WxHxD (mm)
86x350x247 Pack (u.)
1
Hei-TORQUE Ultimate 100 Power supply (W)
90 Speed (rpm)
10-2000 Maximum torque (Ncm)
100 Maximum viscosity (mPas)
60000 Speed indicator
Electronic Maximum stirring volume (l)
50 Weight (Kg)
4.4 Dimensions WxHxD (mm)
86x350x247 Pack (u.)
1
Hei-TORQUE Expert 200 Power supply (W)
120 Speed (rpm)
10-2000 Maximum torque (Ncm)
200 Maximum viscosity (mPas)
100000 Speed control
Electronic Maximum stirring volume (l)
50 Weight (Kg)
5.1 Dimensions WxHxD (mm)
86x350x247 Pack (u.)
1
Hei-TORQUE Ultimate 200 Power supply (W)
120 Speed (rpm)
10-2000 Maximum torque (Ncm)
200 Maximum viscosity (mPas)
100000 Speed control
Electronic Maximum stirring volume (l)
50 Weight (Kg)
5.1 Dimensions WxHxD (mm)
86x350x247 Pack (u.)
1
Hei-TORQUE Expert 400 Power supply (W)
150 Speed (rpm)
Gear I 10 - 400/ Gear II 20 - 2000 Maximum torque (Ncm)
400 Maximum viscosity (mPas)
250000 Speed control
Electronic Maximum stirring volume (l)
100 Weight (Kg)
5.3 Dimensions WxHxD (mm)
93x350x247 Pack (u.)
1
Hei-TORQUE Ultimate 400 Power supply (W)
150 Speed (rpm)
Gear I 10 - 400/ Gear II 20 - 2000 Maximum torque (Ncm)
400 Maximum viscosity (mPas)
250000 Speed control
Electronic Maximum stirring volume (l)
100 Weight (Kg)
5.3 Dimensions WxHxD (mm)
93x350x247 Pack (u.)
1
