Hei-Flow Ultimate peristaltic pumps
- Flow characterisitc of pump heads in combination with various tubing diameters is pre-programmed for accurate flow rate numbers
- Digital read-out of: Speed (rpm), tubing diameter, flow rate in ml/min, dosing volume, interval dosing and pause function
- Easily change all process parameters via these buttons
- It connects to an optional foot-pedal remote control via cable to start and stop your pump drive outside a closed fume hood increasing your personal safety or easy use in multiple sample fills
- This models feature electronic speed control and an accuracy of ± 0.5%
- A press of the max button accelerates the filling and draining of your tube
- At the press of a button the pump operates clockwise or counter-clockwise
- Calibrate your flow volume and flow rate individually
- Control speed (rpm), direction and On/Off function via analog interface for 0 - 10 V or 4 - 20mA or digital RS 232 interface
Supplied without pump heads. Please order separately.
- Power supply: 230 V.
Reproducibility - pumping and dosing. Hei-Flow Ultimate pump includes premium safety standards and features for superior ease of use and reduced cost of ownership, including:
- Flow characterisitc of pump heads in combination with various tubing diameters is pre-programmed for accurate flow rate numbers
- Digital read-out of: Speed (rpm), tubing diameter, flow rate in ml/min, dosing volume, interval dosing and pause function
- Easily change all process parameters via these buttons
- It connects to an optional foot-pedal remote control via cable to start and stop your pump drive outside a closed fume hood increasing your personal safety or easy use in multiple sample fills
- This models feature electronic speed control and an accuracy of ± 0.5%
- A press of the max button accelerates the filling and draining of your tube
- At the press of a button the pump operates clockwise or counter-clockwise
- Calibrate your flow volume and flow rate individually
- Control speed (rpm), direction and On/Off function via analog interface for 0 - 10 V or 4 - 20mA or digital RS 232 interface
Supplied without pump heads. Please order separately.
- Power supply: 230 V.
Hei-Flow Ultimate 120 Speed (min-1)
5 to 120 Flow (ml/min)
0.45 to 935 Multichannel flow (ml/min)
0.005 to 277 Weight (Kg)
7.7 Included head
No Pack (u.)
1
Hei-Flow Ultimate 600 Speed (min-1)
24 to 600 Flow (ml/min)
2.6 to 4500 Multichannel flow (ml/min)
Not recommended Weight (Kg)
7.3 Included head
No Pack (u.)
1
