Marathon P2B-304M compressors station
With air inlet filter (3 µm) and fine filter (0.3 µm) plus safety valve (10 bar), automatic condensate drain, pressure gauge, quick coupling and hose nozzle.
The 90 litres vessel has an internal anti-bacterial coating as standard.
Thanks to the electronic control system (compatible with the network) it is possible to adjust the pressure range electronically. The air quality and the operating pressure of the compressor are indicated.
Suitable for central air supply in small laboratories.
Technical data:
- Nominal voltage (V): 400
- Nominal frequency (Hz): 50/60
- Nominal current (A): 8.8/9.6
- Nominal power (kW): 4.4/5.9
- Protection class (motor): IP54
- Nominal speed (min-1): 1440/1700
- Duty cycle: S1
- Ambient conditions (ºC): From +10 to +40
- Weight (kg): 143
- Dimensions WxHxD (mm): 1020x620x760
Compressor station with two aggregates of 4 cylinders Marathon Type B-304 with 2 membrane dryer systems.
With air inlet filter (3 µm) and fine filter (0.3 µm) plus safety valve (10 bar), automatic condensate drain, pressure gauge, quick coupling and hose nozzle.
The 90 litres vessel has an internal anti-bacterial coating as standard.
Thanks to the electronic control system (compatible with the network) it is possible to adjust the pressure range electronically. The air quality and the operating pressure of the compressor are indicated.
Suitable for central air supply in small laboratories.
Technical data:
- Nominal voltage (V): 400
- Nominal frequency (Hz): 50/60
- Nominal current (A): 8.8/9.6
- Nominal power (kW): 4.4/5.9
- Protection class (motor): IP54
- Nominal speed (min-1): 1440/1700
- Duty cycle: S1
- Ambient conditions (ºC): From +10 to +40
- Weight (kg): 143
- Dimensions WxHxD (mm): 1020x620x760
