Varian/Bruker chromatography inlet liners
Only packs of 5 liners are detailed below. Packs of 1 and 25 liners are also available. See each liner geometry on Varian Bruker Liners A, Varian Bruker Liners B and Varian Bruker Liners C figures.
Only packs of 5 liners are detailed below. Packs of 1 and 25 liners are also available. See each liner geometry on Varian Bruker Liners A, Varian Bruker Liners B and Varian Bruker Liners C figures.
Inlet liners
Description
Split/Splitless FocusLiner® Photo number (Fig.1)
1 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Split/Splitless FocusLiner® Photo number (Fig.1)
1 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Description
Split/Splitless Tapered FocusLiner® Photo number (Fig.1)
2 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Split/Splitless Tapered FocusLiner® Photo number (Fig.1)
2 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Description
Split/Splitless FAST FocusLiner® Photo number (Fig.1)
3 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
2,3 Length (mm)
78,5 Pack (u.)
5
Split/Splitless FAST FocusLiner® Photo number (Fig.1)
3 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
2,3 Length (mm)
78,5 Pack (u.)
5
Description
Split/Splitless Tapered FAST FocusLiner® Photo number (Fig.1)
4 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
2,3 Length (mm)
78,5 Pack (u.)
5
Split/Splitless Tapered FAST FocusLiner® Photo number (Fig.1)
4 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
2,3 Length (mm)
78,5 Pack (u.)
5
Description
Split, straight-through liner Photo number (Fig.2)
1 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Split, straight-through liner Photo number (Fig.2)
1 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Description
Spilt, with quartz wool Photo number (Fig.2)
2 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Spilt, with quartz wool Photo number (Fig.2)
2 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Description
Split/Splitless with single taper Photo number (Fig.2)
3 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Split/Splitless with single taper Photo number (Fig.2)
3 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Description
Split/Splitless with single taper (quartz wool) Photo number (Fig.2)
4 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Split/Splitless with single taper (quartz wool) Photo number (Fig.2)
4 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Description
Split/Splitless with double taper Photo number (Fig.2)
5 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Split/Splitless with double taper Photo number (Fig.2)
5 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Description
Direct, straight-through liner Photo number (Fig.2)
6 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
1,2 Length (mm)
78,5 Pack (u.)
5
Direct, straight-through liner Photo number (Fig.2)
6 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
1,2 Length (mm)
78,5 Pack (u.)
5
Description
Splitless with Recessed Gooseneck Photo number (Fig.2)
7 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
2 Length (mm)
78,5 Pack (u.)
5
Splitless with Recessed Gooseneck Photo number (Fig.2)
7 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
2 Length (mm)
78,5 Pack (u.)
5
Description
Split/Splitless Recessed Gooseneck (quartz wool) Photo number (Fig.2)
8 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Split/Splitless Recessed Gooseneck (quartz wool) Photo number (Fig.2)
8 Equipment
1177 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
78,5 Pack (u.)
5
Description
Split, FAST FocusLiner® Photo number (Fig.2)
9 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
2,3 Length (mm)
72 Pack (u.)
5
Split, FAST FocusLiner® Photo number (Fig.2)
9 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
2,3 Length (mm)
72 Pack (u.)
5
Description
Split with Quartz Wool Photo number (Fig.2)
10 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
72 Pack (u.)
5
Split with Quartz Wool Photo number (Fig.2)
10 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
72 Pack (u.)
5
Description
Split FocusLiner® with Top-end Restriction Photo number (Fig.2)
11 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
72 Pack (u.)
5
Split FocusLiner® with Top-end Restriction Photo number (Fig.2)
11 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
72 Pack (u.)
5
Description
Splitless, Slots at Both Ends Photo number (Fig.2)
14 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
2 Length (mm)
74 Pack (u.)
5
Splitless, Slots at Both Ends Photo number (Fig.2)
14 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
2 Length (mm)
74 Pack (u.)
5
Description
Split FocusLiner® Photo number (Fig.2)
15 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
72 Pack (u.)
5
Split FocusLiner® Photo number (Fig.2)
15 Equipment
1075/1077 Injector External diameter (mm)
6,3 nternal diameter (mm)
4 Length (mm)
72 Pack (u.)
5
Description
Sintered Glass, Large Volume Injection (LVI) Liner Photo number (Fig.2)
16 Equipment
1078/1079 Injector External diameter (mm)
6,3 nternal diameter (mm)
1,8/3,4 Length (mm)
54 Pack (u.)
5
Sintered Glass, Large Volume Injection (LVI) Liner Photo number (Fig.2)
16 Equipment
1078/1079 Injector External diameter (mm)
6,3 nternal diameter (mm)
1,8/3,4 Length (mm)
54 Pack (u.)
5
Description
Straight-through Liner Photo number (Fig.2)
17 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
0,5 Length (mm)
54 Pack (u.)
5
Straight-through Liner Photo number (Fig.2)
17 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
0,5 Length (mm)
54 Pack (u.)
5
Description
SPME liner Photo number (Fig.2)
18 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
0,75 Length (mm)
54 Pack (u.)
5
SPME liner Photo number (Fig.2)
18 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
0,75 Length (mm)
54 Pack (u.)
5
Description
Splitless with Single Taper Photo number (Fig.2)
19 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
2 Length (mm)
54 Pack (u.)
5
Splitless with Single Taper Photo number (Fig.2)
19 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
2 Length (mm)
54 Pack (u.)
5
Description
Split/Splitless with single taper Photo number (Fig.2)
20 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
3,4 Length (mm)
54 Pack (u.)
5
Split/Splitless with single taper Photo number (Fig.2)
20 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
3,4 Length (mm)
54 Pack (u.)
5
Description
Split/Splitless FocusLiner® Photo number (Fig.2)
21 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
3,4 Length (mm)
54 Pack (u.)
5
Split/Splitless FocusLiner® Photo number (Fig.2)
21 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
3,4 Length (mm)
54 Pack (u.)
5
Description
Split/Splitless Tapered FocusLiner® Photo number (Fig.2)
22 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
3,4 Length (mm)
54 Pack (u.)
5
Split/Splitless Tapered FocusLiner® Photo number (Fig.2)
22 Equipment
1078/1079 Injector External diameter (mm)
5 nternal diameter (mm)
3,4 Length (mm)
54 Pack (u.)
5
Description
ConnecTite® SPI Liner, (Restriction = 0,25 mm) Photo number (Fig.2)
23 Equipment
1093/1094 Injector External diameter (mm)
4,6 nternal diameter (mm)
0,5 Length (mm)
54 Pack (u.)
5
ConnecTite® SPI Liner, (Restriction = 0,25 mm) Photo number (Fig.2)
23 Equipment
1093/1094 Injector External diameter (mm)
4,6 nternal diameter (mm)
0,5 Length (mm)
54 Pack (u.)
5
Description
ConnecTite® SPI Liner, (Restriction = 0,5 mm) for 0,53 mm ID On-column Photo number (Fig.2)
24 Equipment
1093/1094 Injector External diameter (mm)
4,6 nternal diameter (mm)
0,8 Length (mm)
54 Pack (u.)
5
ConnecTite® SPI Liner, (Restriction = 0,5 mm) for 0,53 mm ID On-column Photo number (Fig.2)
24 Equipment
1093/1094 Injector External diameter (mm)
4,6 nternal diameter (mm)
0,8 Length (mm)
54 Pack (u.)
5
Description
ConnecTite® SPI Liner, (Restriction = 0,25 mm) Photo number (Fig.2)
25 Equipment
1093/1094 Injector External diameter (mm)
4,6 nternal diameter (mm)
0,8 Length (mm)
54 Pack (u.)
5
ConnecTite® SPI Liner, (Restriction = 0,25 mm) Photo number (Fig.2)
25 Equipment
1093/1094 Injector External diameter (mm)
4,6 nternal diameter (mm)
0,8 Length (mm)
54 Pack (u.)
5
O-Rings and Sealing Rings
Description
Viton O-Ring Use
Temperature up to 300°C, for liners with Ext Ø 6,3mm Pack (u.)
10
Viton O-Ring Use
Temperature up to 300°C, for liners with Ext Ø 6,3mm Pack (u.)
10
Description
Graphite Ring Use
1078 & 1079 Injectors Pack (u.)
10
Graphite Ring Use
1078 & 1079 Injectors Pack (u.)
10
Equipment
Injectors/detectors at atmospheric pressure (FID) (not GC-MS) Column internal diameter
1/4" ED packed Ferrule internal diameter
1/4" Pack (u.)
10
Injectors/detectors at atmospheric pressure (FID) (not GC-MS) Column internal diameter
1/4" ED packed Ferrule internal diameter
1/4" Pack (u.)
10
